LOGICA 07

The Facts:

• Operation: All electric with touch screen control
• Printing Force: 11000 N
• Max Print Speed: adjustable up to 1200 c/h*
• Number of Colors: 1-2-3-4-5-6-7-8
• Max Cup Diameter: 250 mm
• Standard Cup Sizes: 5X250 or 6X195 or 7X160 or 8X130mm (or a mix of different sizes as required)
• Pad Register: +/- 40mm
• Vertical Stroke: 160 mm
• Max Pad Height: 270 mm
• Power: 380/400 V - triple phase - 50/60 Hz
• Weight: About 1500 Kg
• Dimensions: 1370 x 1820 x 2300 mm (h)

*We’re going to make your machine go fast and print large, but final speeds and print areas will vary from what’s specified above, based on the application.
